3M Double Sided Tapes

3M 9077 Double Coated Tape

Online inquiry

products names(*):

Address:

Email:

The Phone:

Name(*):

Fax:

Leave a message:

PRODCUTS OVERVIEW

3M 9077 Ultra High Temperature Double Coated Tape  is a 2.0 mil clear double-coated adhesive tape designed for continued adhesion in high-temperature environments up to 500°F/260°C. It features a 2 mil 3M Ultra High Temperature Acrylic Adhesive 100HT, excellent for use in FPC attachment and for HSE metals. A 3.6 mil heat-resistant non-woven liner adds stability for die-cutting and converting.


  • High temperature adhesive and release liner survives short term exposure to 500°F/260°C for lead-free solder reflow
  • Maintains high adhesion strength in high temperatures, excellent for heat-intensive processing
  • Ideal for flexible printed circuit (FPC) attachments and HSE metals
  • High adhesion, excellent holding power and low outgassing

Recommended Applications

  • Printed circuit boards
  • Flexible circuits
  • Automotive underhood
  • Heat sink bonding

About 3M Ultra High Temperature Acrylic Adhesive 100HT
3M 9077 Ultra High Temperature Double Coated Tape  features 3M Ultra High Temperature Acrylic Adhesive 100HT, an acrylic adhesive that withstands up to 540°F (280°C) short-term heat resistance and 350°F (175°C) long term temperature tolerance. It delivers much higher adhesion strength at high temperatures than traditional PSA transfer tapes, as well as excellent holding power and low outgassing.
